SR系列输出扭矩表

产品描述：型号弹簧组弹簧力矩供气压力(bar) 2.5 3 4 5 输出扭矩(Nm) 0 MMD 90 MMC 0 MAD 90 MAC 0 MAD 90 MAC 0 MAD 90 MAC 0 MAD 90 MAC SR52 01 3.6 4.9 4.5 1.6 6.4 3.5 10...

联系电话：13851461098

立即咨询联系我们

详细介绍

型号	弹簧组	弹簧力矩		供气压力(bar)
				2.5		3		4		5
				输出扭矩(Nm)
		0° MMD	90° MMC	0° MAD	90° MAC	0° MAD	90° MAC	0° MAD	90° MAC	0° MAD	90° MAC
SR52	01	3.6	4.9	4.5	1.6	6.4	3.5	10.2	7.4
	02	4.8	6.7			5.2	1.7	9.0	5.6	12.8	9.4
	03	5.2	7.5					8.6	4.8	12.4	8.6
	04	6.5	9.3					7.3	3.0	11.2	6.8
	05	8.1	11.9							9.5	4.3
SR63	01	5.0	9.6	8.6	2.6	12.0	6.0	18.9	12.8
	02	6.6	12.3			10.5	3.2	17.4	10.1	24.2	17.0
	03	8.0	14.5					15.9	7.9	22.8	14.8
	04	9.6	17.2					14.4	5.2	21.2	12.0
	05	12.5	22.1							18.2	7.1
SR75	01	10.1	19.5	15.8	3.9	22.0	10.1	34.4	22.5
	02	13.3	25.6			18.8	4.0	31.2	16.4	43.5	28.7
	03	15.1	28.8					29.4	13.8	41.8	26.1
	04	18.3	34.3					26.2	7.7	38.6	20.0
	05	23.2	43.0							33.6	11.3
SR85	01	16.1	27.3	22.2	7.6	31.3	16.6	49.5	34.8
	02	19.9	33.7			27.6	10.3	45.7	28.4	63.9	46.6
	03	24.3	40.8					41.3	21.3	59.4	39.5
	04	28.1	47.1					37.5	15.0	55.7	33.1
	05	36.3	60.6							47.5	19.6
SR100	01	24.6	44.6	36.0	10.1	50.2	24.2	78.4	52.5
	02	19.9	33.7			42.2	9.9	70.5	38.1	98.7	66.4
	03	35.9	63.7					67.1	33.3	95.4	61.6
	04	43.9	78.0					59.1	19.0	87.4	47.3
	05	55.2	97.2							76.1	28.1
SR115	01	41.0	74.4	61.3	18.4	84.7	41.8	131.4	88.5
	02	50.7	94.4			74.9	21.8	121.6	68.5	168.3	115.2
	03	60.8	108.1					111.6	54.7	158.3	101.5
	04	40.6	128.1					101.8	34.8	148.5	81.5
	05	90.4	161.8							128.7	47.8
SR125	01	53.1	99.1	80.2	21.2	110.9	51.9	172.2	113.2
	02	63.3	117.5			100.7	33.5	162.1	94.8	223.4	156.1
	03	81.1	148.4					144.2	63.9	205.5	125.2
	04	70.6	128.1					134.1	45.5	195.4	106.8
	05	119.2	216.2							167.4	57.5
SR160	01	100	152	186	126	245	188
	02	147	225			198	116	317	234
	03	173	264			170	74	290	193	407	311
	04	200	321					260	136	378	255
	05	252	376							330	191
	06	300	473
SR200	01	174	245	362	270	472	387
	02	247	356			398	273	621	498
	03	298	424			344	192	568	425	789	649
	04	353	531					510	317	731	541
	05	421	602							655	447
	06	527	776
SR270	01	202	788	834	545	1109	819	1658	1368
	02	606	946	726	379	1001	654	1550	1203
	03	707	1103	619	214	893	488	1442	1037	1991	1586
	04	808	1261	511	48	785	323	1334	872	1884	1421
	05	909	1418			678	157	1227	706	1776	1255
	06	1010	1576					1119	540	1668	1090
	07	1111	1733					1011	375	1560	924
	08	1213	1891					904	209	1453	758

型号	弹簧组	弹簧力矩		供气压力(bar)
				5.5		6		7		8
				输出扭矩(Nm)
		0° MMD	90° MMC	0° MAD	90° MAC	0° MAD	90° MAC	0° MAD	90° MAC	0° MAD	90° MAC
SR52	01	3.6	4.9
	02	4.8	6.7
	03	5.2	7.5	14.3	10.5	16.2	12.4
	04	6.5	9.3	13.1	8.7	15.0	10.6	18.8	14.5
	05	8.1	11.9	11.4	6.2	13.3	8.1	17.1	11.9	20.9	15.7
SR63	01	5.0	9.6
	02	6.6	12.3
	03	8.0	14.5	26.2	18.2	29.6	21.7
	04	9.6	17.2	24.6	15.5	28.1	18.9	34.9	25.8
	05	12.5	22.1	21.7	10.6	25.1	14.0	31.9	20.9	38.8	27.7
SR75	01	10.1	19.5
	02	13.3	25.6
	03	15.1	28.8	48.0	32.3	54.1	38.5
	04	18.3	34.3	44.8	26.2	50.9	32.4	63.3	44.8
	05	23.2	43.0	39.8	17.5	46.0	23.7	58.3	36.1	70.7	48.4
SR85	01	16.1	27.3
	02	19.9	33.7
	03	24.3	40.8	68.5	48.6	77.6	57.6
	04	28.1	47.1	64.8	42.2	73.8	51.3	92.0	69.4
	05	36.3	60.6	56.6	28.7	65.6	37.8	83.8	55.9	101.9	74.1
SR100	01	24.6	44.6
	02	19.9	33.7
	03	35.9	63.7	109.5	75.7	123.6	89.9
	04	43.9	78.0	101.5	61.4	115.7	75.5	143.9	103.8
	05	55.2	97.2	90.2	42.3	104.3	56.4	132.6	84.7	160.8	112.9
SR115	01	41.0	74.4
	02	50.7	94.4
	03	60.8	108.1	181.6	124.8	205.0	148.2
	04	40.6	128.1	171.9	104.9	195.2	128.2	241.9	174.9
	05	90.4	161.8	152.0	71.1	175.4	94.5	222.1	141.2	268.8
SR125	01	53.1	99.1
	02	63.3	117.5
	03	81.1	148.4	236.2	155.9	266.8	186.5
	04	70.6	128.1	226.1	137.5	256.7	168.1	318.0	229.4
	05	119.2	216.2	198.1	88.1	228.7	118.8	290.1	180.1	351.4	241.4
SR160	01	100	152
	02	147	225
	03	173	264
	04	200	321	437	312
	05	252	376	388	251	447	310
	06	300	473	335	161	395	220	512	332	627	445
SR200	01	174	245
	02	247	356
	03	298	424
	04	353	531	842	651
	05	421	602	767	562	878	675
	06	527	776	662	396	777	510	994	721	1209	935
SR270	01	202	788
	02	606	946
	03	707	1103
	04	808	1261	2158	1695
	05	909	1418	2050	1530	2325	1804
	06	1010	1576	1943	1364	2217	1639
	07	1111	1733	1835	1198	2109	1473	2659	2022
	08	1213	1891	1727	1033	2002	1307	2551	1856	3100	2405
